QMA RF CONNECTOR
QMA PLUG TO N PLUG ADAPTER
Description
RF Connector QMA 500hm Plug To N Plug Straight Adapter Material and Plating
Customer Drawing ADD INQUIRY Product Specifications
| Body | Brass@ Nickel 80~120u" |
| Shell | Brass@ Nickel 80~120u" |
| Insulator | PTFE (Teflon) |
| Center Contact | Brass@ CuSnZn 80~100u" |
| Ground | Phosphor bronze@ Nickel 80~120u" |
| Gasket | Silicone |
| Snap Ring | SUS304 |
| Impedance | 50 Ohm |
| Frequency Range | DC ~ 12 GHz |
| VSWR | 1.25 max. |
| Working Voltage | 500 V rms |
| Insertion Loss | ≤ 0.3 dB |
| Insulator Resistance | ≥ 5 GR |
| Center Contact Resistance | ≤2.0 ml |
Environmental
RoHS and REACH compliant
